Home » Products » Welding Machine Rectifiers » DC Welding Rectifiers

DC Welding Rectifiers

DC Welding Rectifiers
DC Welding Rectifiers
Product Code : WR 02
Brand Name : VULCAN
Trade Information
  • Price
  • Minimum Order Quantity
  • ,
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Packaging Type: Standard Packaging Packaging Quantity: Single piece per box
  • Certifications
  • ISO 9001:2000 Certification
Product Description

DC Welding Rectifiers

DC Welding Rectifier is an ultra-modern industrial welding machinery that is designed and developed with due efficiency by the knowledgeable professionals of our company. The machinery are constantly being praised because of its advanced quality, modern features and other such attributes. We are said to be one of the dynamic manufacturers of DC Welding Rectifier as customers surely get high performance machinery from us. The layouts of the machinery are prepared well in advance so that while engineering the machinery the notes are taken by the production experts. For several welding applications the welding rectifiers are needed.

Features:

  • Easy to operate
  • Low maintenance requirement
  • Resistant to impact and abrasion

Salient Features:

  • Genuine Vertical Qualities
  • Consistent Arc With Simple Droplet Exchange
  • Remote Current Manage Unit (Discretionary)
  • Tropical And Reliable Design
  • Epoxy Powder Covered Body For Corrosion Free Long Life
  • Twisting Varnishing By Void Pressurized Infusing System To Improve Service Life And Reliability
  • Wonderful Soldering Performance With Every Kind Of S.S. Electrodes And Alloy Steel Comprising 7018, 6010 Cellulosic And 6013

Specifications:

PARTICULARS

UNITS

WR20TD

WR30TD

WR40TD

WR60TD

Input Supply

Valts

415 V, 3 Phase, 50 Hzs. AC

Open Circuit Voltage (OCV) (Max.)

V. DC

80

90

Welding Current Range with low & High Range Selection

Amps. DC

30 – 200

30 – 300

40 – 400

60 – 600

Max. Welding Current @ 60% Duty Cycle

Amps.

200

300

400

600

Rating

KVA

12

17

22

40

Current Regulation Type

Amps.

Stepless (Remote Optional)

Insulation

Class

H (Copper Wound)

Cooling


Forced Air Cooled

Max. Dimensions (Approx) (L x W x H)

M.M.

870 x 510 x 895

940 x 605 x 940

1030 x 650 x 995

Weight Without Remote (Approx)

Kgs.

190

225

240

350

Confirm to


IS – 4559 – 1993
